Off-Road Lights Symbol 4 gives your accessory lighting circuit a dedicated legend in the CH4x4 Small Push range. The laser-etched design sits on a matte black face, providing an OEM-style finish for a panel with several added controls.
Choose Off-Road Lights Symbol 4 for the legend
The design number identifies this artwork option. It does not represent a different beam pattern, lighting mode or load rating. Compare the product image with Symbol 5 or Symbol 3 before selecting the label you prefer.
Control and illumination
The electronic switch is rated at 12V 3A and includes short circuit protection. Its Single Pole Single Throw ON/OFF action controls the assigned accessory circuit. The upper LED illuminates when the button is pressed IN; the lower LED can connect to a separate dash-light circuit.
Use the supplied diagram to plan those two light connections. The button provides an on/off function rather than dimming or changing the connected lamps’ output.
Small Push size and vehicle applications
Heavy-duty ABS construction supports the matte black hard face. Dimensions are 32.5 × 22 mm, approximately 1.28 × 0.87 inches. Match the available opening and vehicle year before choosing this switch, which is compatible with Toyota applications below.
- Toyota Tacoma 2012–2023 (Center Console ONLY)
- Toyota Tundra 2008–2021
- Toyota 4Runner 2010–2024
- Toyota Land Cruiser Prado 150 Series 2010–2014
- Toyota Land Cruiser 200 Series 2008–2013
- Toyota Sequoia 2008–2014
- Toyota Corolla 2006–2013
- Toyota Camry 2011–2014
Tacoma fitment is Center Console ONLY. Check the intended position instead of assuming every blank in the vehicle uses this format.
Prepare the relay circuit
The accessory MUST be wired through a fused relay in ALL cases. Select the fuse, relay and load wiring for the actual lights, and follow the supplied switch diagram. The 3A button rating does not remove that relay requirement.
One Small Push ON/OFF switch and one connector with cable are included; a wiring diagram is supplied. Review the relay with 5-pin harness specifications when planning parts.
The relevant Toyota owner’s manual provides information about original controls. Use that reference when choosing a clear position for the Off-Road Lights Symbol 4 button.
