LED Light Bar Symbol 2 offers an alternate design for identifying a light-bar accessory circuit. The laser-etched legend sits on a matte black hard face, giving the control a factory look without leaving the circuit marked by a blank button.
Start with the mounting space
The face measures 32.5 × 22 mm, approximately 1.28 × 0.87 inches. Check the opening at your chosen position, then match the vehicle year below. An OEM-style finish alone does not confirm the correct switch format for every location.
Compatible with Toyota applications listed
- Toyota Tacoma 2012–2023 (Center Console ONLY)
- Toyota Tundra 2008–2021
- Toyota 4Runner 2010–2024
- Toyota Land Cruiser Prado 150 Series 2010–2014
- Toyota Land Cruiser 200 Series 2008–2013
- Toyota Sequoia 2008–2014
- Toyota Corolla 2006–2013
- Toyota Camry 2011–2014
The Tacoma application is Center Console ONLY. Verify that restriction before arranging this button alongside other lighting controls.
LED Light Bar Symbol 2 specifications
The control is a 12V 3A electronic Single Pole Single Throw ON/OFF switch with short circuit protection. Heavy-duty ABS construction supports the matte black face and laser-etched artwork.
One upper LED illuminates when the button is pressed IN. One lower LED can connect to a separate dash-light circuit. Use the supplied diagram to plan these two light connections rather than assuming both follow the same circuit.
Compare the artwork and plan the load wiring
LED Light Bar Symbol 2 names the design option; it does not describe a different light-bar capacity or beam setting. Compare the standard LED Light Bar symbol before deciding which legend you prefer on your panel.
The accessory MUST be wired through a fused relay in ALL cases. Choose the relay, fuse and load wiring for the connected light bar’s actual requirements. The button supplies ON/OFF control, not dimming or a change in the light’s output characteristics.
Package contents
One Small Push ON/OFF switch and one connector with cable are included; a wiring diagram is supplied. Explore the Small Push Series if you need other labels for adjacent accessory circuits.
The appropriate Toyota owner’s manual is a reference for original vehicle controls. Use it when planning the panel location, and follow the supplied diagram for the added switch connections.
