Air Compressor Symbol 2 is a graphic option for the CH4X4 Small Push range. If you are matching the legends across an accessory panel, use the image on this page to select the second compressor design and keep the control easy to identify.
Select the Air Compressor Symbol 2 artwork
The legend is laser etched into the hard black face rather than supplied as a separate label. A matte black finish and heavy-duty ABS construction give the housing an OEM-style appearance for compatible Toyota interiors. The face measures 1.28 × 0.87 in (32.5 × 22 mm).
Compare this version with the standard compressor graphic and third compressor design. Choosing the symbol is about identifying your control; it does not change the electrical rating or supply the compressor itself.
What is included
Your kit contains one Small Push switch and one connector with cable. A wiring diagram is supplied to guide the electrical connections. Confirm the switch location before fitting the connector and routing the wires.
Panel fitment reference
- Toyota Tacoma 2012–2023 (Center Console ONLY)
- Toyota Tundra 2008–2021
- Toyota 4Runner 2010–2024
- Toyota Land Cruiser Prado 150 Series 2010–2014
- Toyota Land Cruiser 200 Series 2008–2013
- Toyota Sequoia 2008-ON
- Toyota Corolla 2006–2013
- Toyota Highlander 2008-ON
- Toyota RAV4 2008–2012
- Toyota Yaris 2008
- Toyota Camry 2011–2014
For entries marked “ON,” confirm the exact model year and switch location before ordering; the designation does not verify every later generation.
The Tacoma entry is for the center console only. The model list and face dimensions should both be checked against the intended installation position.
ON/OFF operation and LED connections
Air Compressor Symbol 2 uses a Single Pole Single Throw electronic switch rated at 3A, 12V, with short circuit protection. Its upper LED illuminates when pressed IN; the lower LED can be wired to a separate dashboard light circuit for label illumination.
The accessory MUST use a fused relay in all installations. Plan the compressor power circuit around its own requirements and follow the supplied switch diagram. The relay with 5-pin harness is listed separately.
