The Weboost Symbol push switch gives a suitable equipment power-control circuit an identifiable panel button. This CH4x4 Small Push item supplies the control switch, not a signal booster or communications equipment.
Weboost Symbol electrical planning
Verify the specific equipment’s supply and control-input requirements before connecting the button. It is an electronic Single Pole Single Throw ON/OFF switch, rated at 3A at 12V, with short circuit protection.
The accessory MUST be wired through a fused relay in ALL cases. Follow the supplied switch diagram and the equipment manufacturer’s instructions. The 12V switch rating does not establish the output required by every power adapter or connected device.
What the indicator means
The upper LED turns ON when the button is pressed IN. It indicates the switch state, not signal strength or connection status. The lower LED can connect to a separate dash-light circuit for panel illumination.
OEM-style face and dimensions
The face measures 32.5 × 22 mm, approximately 1.28 × 0.87 inches. A heavy-duty ABS body and matte black hard surface give a factory look, with the Weboost Symbol marking laser etched directly into the face.
Compatible with Toyota mounting applications
Check your model year and switch opening. Tacoma uses the center-console position only. For entries marked ON, verify the exact year and available mounting space.
- Toyota Tacoma 2012–2023 (Center Console ONLY)
- Toyota Tundra 2008–2021
- Toyota 4Runner 2010–2024
- Toyota Land Cruiser Prado 150 Series 2010–2014
- Toyota Land Cruiser 200 Series 2008–2013
- Toyota Sequoia 2008–ON
- Toyota Corolla 2006–2013
- Toyota Highlander 2008–ON
- Toyota RAV4 2008–2012
- Toyota Yaris 2008
- Toyota Camry 2011–2014
Included components
The package includes one Small Push ON/OFF switch and one connector with cable, with a wiring diagram supplied.
A booster, antenna, power adapter and fused relay are not listed package contents. Compare the Small Push control range to coordinate the panel. Consult the applicable Toyota owner’s manual when identifying original vehicle controls.
