CH4x4 Momentary Rocker Switch Winch IN-OUT Symbol – Horizontal – 12V/24V Twin-Light Laser-Etched Momentary Switch

CH4x4 Momentary Rocker Switch Winch IN-OUT Symbol – Horizontal – 12V/24V Twin-Light Laser-Etched Momentary Switch

$21.98

CH4x4 Momentary Rocker Switch Winch IN-OUT Symbol – Horizontal is a double throw momentary switch (returns to center position by the spring) designed to operate your 12 volt 4WD Winch.

Switch LED Color

Clear

Description
Additional information

The Momentary Rocker Switch Winch IN-OUT is a spring-loaded momentary rocker switch, returning to center automatically, ideal for winches, horns, and anything you only want on briefly.

The symbol is precision laser etched into the switch face itself, built to outlast years of sun, wash bays, and trail use without fading or peeling.

Twin Light Indicator

Two indicator lights are built in, tied to switch position:

Upper lights turn ON when the switch is pressed UP
Lower light turns ON when the switch is pressed DOWN
Springs back to center automatically, lights off, when released

Features

Double Pole Double Throw Momentary switch
Black hard-surface rocker body
Laser-etched design, never a sticker
Twin incandescent indicator lights
Rated 20A at 12V / 10A at 24V
Carling / Contura V-style mounting format
Snap-in panel installation, no rear terminal barriers
Wiring diagram included
Works across automotive, 4×4, truck, UTV, ATV, RV, and marine builds

Dimensions

Switch Face: 2" x 1" (50mm x 25mm)
Mounting Cutout: 0.86" x 1.46" (22mm x 37mm)

Note: This is a universal aftermarket rocker switch, not a factory-specific replacement part. Confirm your panel’s cutout dimensions before ordering — some vehicles may need an adapter panel or minor modification to fit.

Weight	2 oz
Dimensions	5 × 5 × 2 in
Switch Action	Momentary
Vehicle	Symbol Designs
Switch LED Color	Amber, Blue, Green, Red, White
Switch Type	Rocker
Function	Momentary
Controls	Winch
Voltage	12V 20A, 24V 10A
Compatibility	Carling, Contura V
Orientation	Horizontal

Built For Real-World Use

Every CH4x4 Momentary Rocker Switch Winch IN-OUT Symbol – Horizontal – 12V/24V Twin-Light Laser-Etched Momentary Switch is laser-etched directly into the switch face — not printed or stickered — so the design holds up to years of sun, wash bays, and trail use instead of fading or peeling off. A universal-fit switch — not vehicle-specific — so it drops into any standard 12V dash opening.

Frequently Asked Questions

Is this switch On-Off or Momentary?

This is a Momentary switch — it only stays active while you hold it and springs back off, ideal for horns, winches, and anything you only want on for a moment.

What vehicles is this switch compatible with?

This is a universal-fit switch — it's not vehicle-specific, so it works in any 12V application with a matching dash cutout.

Is the design laser-etched or a sticker?

Laser-etched, directly into the switch face — not a sticker or ink print, so the design won't fade, peel, or wear off over time.

What do I need to install this switch?

Just basic hand tools and simple 12V wiring — this switch drops into a standard dash opening and wires the same as any single-pole 12V accessory switch.
